Important Information
CAUTION: Risk of personal injury. Do not use the oor-mount bath faucet as
a grab bar or support bar when entering or exiting the bath. The oor-mount
bath faucet is not designed to support weight.
NOTICE: To avoid damage to the O-rings on the boom of the faucet, keep the faucet
vertical during installation.
NOTE: A minimum operating pressure of 45 psi (310 kPa) is required for proper
operation. If a pressure of less than 45 psi (310 kPa) is present, contact a plumber or
choose another faucet.
NOTE: For use with automatic compensating valves rated at 1.6 gal/min (6.1 l/min)
or less.
Follow all local plumbing and building codes.
The faucet shown in this Installation Instructions may dier from your actual
product. The installation steps still apply.
Turn OFF the water supply.
A drill bit is provided for installation to wood support. Use an appropriate drill
bit for other materials.
The dimensions given assume that the spout and bath are mounted on the same
surface. Adjust the dimensions accordingly if the spout and bath are mounted on
dierent surfaces.
If this product is installed with an overowing bath, the outer rim of the bath
should slightly overlap the 2x4 framing.
Installer-supplied copper tubing must be 5/8″ OD (1/2″ Nominal).
Carefully review this Installation Instructions and all appropriate roughing-in
information. Design the bath enclosure accordingly.
Kohler Co. 3
1443292-2-B
