Kohler Courage SH265 Service Manual

48
Reassembly
KohlerEngines.com 18 690 01 Rev. B
Install Retractable Starter
1. Install retractable starter on blower housing using screws. Finger tighten screws only.
2. Pull rope handle to engage pawls and center starter to drive cup. Hold in this position and torque screws to
5.4 N·m (47.8 in. lb.).
External Engine Components
D
J
E
F
G
I
C
A
H
B
K
A Oil Drain Plug B Oil Fill Plug C Muffl er Assembly D Breather Hose
E Air Cleaner Cover F Element/Precleaner G Air Cleaner Base H Carburetor Cover
I Fuel Tank J Fuel Tank Filter K Low-Profi le Air
Cleaner

Kohler Courage SH265 Specifications

General

Compression Ratio	8.5:1
Lubrication	Splash
Governor Type	Mechanical
Air Cleaner	Dual element
Starter Type	Recoil
Engine Type	OHV
Power	6.5 hp
Fuel Capacity	1.0 gal. (3.8 L)
Oil Capacity	0.6 liters
Ignition System	Electronic
Valve Configuration	Overhead Valve (OHV)
Dry Weight	16 kg (35 lbs)
