Kohler Courage SV730

69
Reassembly
32 690 01 Rev. G KohlerEngines.com
Crankshaft/Governor Gear/Oil Pump Components
K
J
L
O
Q
P
G
H
I
D
C
B
A
E
F
N
M
R
12
S
T
U
V
Y
W
X
X
W
A
Governor Cross
Shaft
B Crankshaft C Valve Tappets D Camshaft
E Regulating Pin F Shaft G Governor Gear H
Locking Tab Thrust
Washer
I Oil Pan (Style A) J Drain Plug K Oil Seal L
Oil Feed Tube
(Filter to Pan)
(Style A)
M Oil Pump (Style A) N
Gerotor Gears
(Style A)
O
Oil Feed Tube
(Oil Pump Outlet)
(Style A)
P O-Rings (Style A)
Q Oil Sentry
™
R
Oil Pump Torque
(Style A)
S
Retaining Ring
(Style A)
T Oil Pan (Style B)
U Oil Pump (Style B) V
Oil Pick-up Screen
(Style B)
W Ball X Spring
Y Ground Strap Location
