Kohler Courage XT-6

9.2
Section 9
Inspection and Reconditioning
90°
20.5 mm
5.500/5.5.12 mm
23.875/24.125 mm
45°
0.80 mm
5.465/5.480 mm
90°
22.6 mm
5.500/5.5.12 mm
25.875/26.125 mm
45°
0.80 mm
5.465/5.480 mm
Exhaust Valve
Intake Valve
A
A
B
B
C
C
F
F
E
E
D
D
A
B
C
D
E
F
G
ȱ
Guide Depth
Guide I.D.
Valve Head Diameter
ȱȱ
Valve Margin (Min.)
ȱȱ
Dimension
Intake Exhaust
Figure 9-1. Valve Details.
