23
Fuel System
18 690 01 Rev. G KohlerEngines.com
• Inspect carburetor body for cracks, holes, and other
wear or damage.
• Inspect float for cracks, holes, and missing or
damaged float tabs. Check float hinge and shaft for
wear or damage.
• Inspect fuel inlet needle and seat for wear or damage.
1. Perform removal procedures for appropriate air
cleaner and carburetor outlined in Disassembly.
2. Clean exterior surfaces of dirt or foreign material
before disassembling carburetor. Remove bowl
retaining screws, and carefully separate fuel bowl
from carburetor. Do not damage fuel bowl O-rings.
Transfer any remaining fuel into an approved
container. Save all parts. Fuel can also be drained
prior to bowl removal by loosening/removing bowl
drain screw.
3. Remove float pin and inlet needle. Seat for inlet
needle is not serviceable and should not be
removed.
4. Clean carburetor bowl and inlet seat areas as
required.
5. Carefully remove main jet from carburetor. After
main jet is removed, main nozzles can be removed
through bottom of main towers. Note orientation/
direction of nozzles. End with 2 raised shoulders
should be out/down adjacent to main jets.
6. Save parts for cleaning and reuse unless a jet kit is
also being installed. Clean slow jets using
compressed air or carburetor cleaner, do not use
wire.
NOTE: There are 2 O-rings on body of idle jet.
Carburetor is now disassembled for appropriate cleaning
and installation of parts in overhaul kit. See instructions
provided with repair kits for more detailed information.
High Altitude Operation
If this engine is operated at an altitude of 4000 ft.
(1219 meters) or above, a high altitude carburetor
kit is required. To obtain high altitude carburetor kit
information or to fi nd a Kohler authorized dealer, visit
KohlerEngines.com or call 1-800-544-2444 (U.S. and
Canada).
This engine should be operated in its original
confi guration below 4000 ft. (1219 meters).
Operating this engine with the wrong engine
confi guration at a given altitude may increase its
emissions, decrease fuel effi ciency and performance,
and result in damage to the engine.
