Disassembly/Inspection and Service
WARNING
Before working on engine or equipment, disable engine as
follows: 1) Disconnect spark plug lead(s). 2) Disconnect
negative (–) battery cable from battery.
Accidental Starts can cause severe injury or
death.
Disconnect and ground spark plug lead(s)
before servicing.
18 690 01 Rev. G KohlerEngines.com
External Engine Components
D
J
E
F
G
I
C
A
H
B
K
A Oil Drain Plug B Oil Fill Plug C Muffl er Assembly D Breather Hose
E Air Cleaner Cover F Element/Precleaner G Air Cleaner Base H Carburetor Cover
I Fuel Tank J Fuel Tank Filter K
Low-Profi le Air
Cleaner
