Kohler Courage User Manual

5
Specifi cations
18 690 01 Rev. G KohlerEngines.com
369.40
[14.543]
113.44
[4.466]
273.97
[10.786]
88.00
[3.465]
339.90
[13.382]
106.00
[4.173]
30.00
[1.181]
METRIC FLANGE: 4X M8 X 1.25-6H
THRU
SAE A FLANGE: 4X 5/16-24 UNF-2B THRU
METRIC FLANGE: 4X M8 X 1.25-6H
15.00 [0.591]
SAE A FLANGE: 4X
5/16-24 UNF-2B 15.00 [0.591]
162.00
[6.378]
342.20
[13.473]
65.05
[2.561]
32.53
[1.281]
66.00 [2.598]
32.53 [1.281]
65.05 [2.561]
318.66
[12.545]
STRAIGHT PTO
181.60
[7.150]
SPARK
PLUG
OIL FILL
DRAIN PLUG
37.98 [1.495]
37.50 [1.476]
78.00
[3.071]
2X Ø 10.00 [0.394]
2X 10.00 X 15.50
SLOT [0.394 X 0.610]
110.00 [4.331]
AIR CLEANER
COVER
REMOVAL
12.50
[0.492]
GAS CAP
REMOVAL
Engine Dimensions
Dimensions in millimeters.
Inch equivalents shown in [ ].
