Kohler GM87448 User Manual

10 TP-7077 3/19
2.1 Component Overview
Green
1. Battery charger
2. Mounting holes
3. Power cord
4. Communication port
5. Temperature sensor port
6. Black lead
7. Red lead
8. Fuse, 20A
9. LED indicators
9
2
3
4
5
6
7
8
1
Figure 1 Battery Charger Overview
2.2 Features
 12 or 24 VDC output
 Automatic multi-stage charging modes
o Recovery (soft start when attached battery is below depleted battery setting)
o Bulk (constant current operation)
o Absorption (constant voltage charge)
o Float (maintenance charge)
o Equalize (manual/auto)
 Charges the following type batteries:
o Flooded lead acid (FLA)
o AGM
o Gel cell
o High performance AGM
o Nickel-cadmium (Ni-Cad)
 5 LED status indicators
 Durable potted assembly for full waterproofing and vibration resistance
 Reverse-polarity protection
 Short-circuit protection
 Electronically limited output current
 Optional temperature compensation (FLA only)
 User adjustable parameters to support optimal manufacturer recommended charge curve.
 Code compliance:
o UL 1236 Listed
o NFPA 110, Level 1 compatible (when used with Kohler controller and connected to engine harness)
o CSA – C22.2 No. 107.2-01
o FCC – Title 47, Part 15 Class A
o CE
o IBC 2015
o OSHPD
