Service Parts
**Finish/color code must be specified when ordering.
93836
93838
93839
94853
(1/2")
(1")
(1-1/4")
(1-1/2")
Tube (with Couplings)
1041995**
Air Switch
To Pump
1042083
Tubing Nut
93685
Housing
96708
Flange
65054**
Screw
73518
Plug
1008239
Flange
67665
Plug
1008244**
Eyeball
1008243**
Sleeve
1013249
Nozzle
1013250
Nut
65226**
Suction Cover Plug
96895**
Suction Cover
1008242**
Trim Ring
65886
Gasket
1003065
Suction Flange
Removal Tool
1008238
Jet Housing
1008241
Gasket
91967
Check Valve
1011001
Flange Removal Tool
1015255**
Jet Trim
1015161
Jet Trim Tool
1010997-5-F 8 Kohler Co.
