7. Installation Checkout
Attach the clips (provided) evenly along the hose and power cord
to organize them.
Wrap the toilet seat with plastic wrap. This will prevent water
from spraying from the toilet during testing.
Plug the power cord into the GFCI- or RCD-protected receptacle.
When the seat is plugged in, the seat will go through a power-up
sequence where the wands will extend and retract, and the power
indicator LED will flash amber then green.
The seat is activated by skin-to-seat contact. Unless otherwise
stated, the seat must be occupied to activate the functions. To
activate the seat controls for testing purposes, when facing the
toilet, place your hand or a damp wash cloth on the right side of
the seat approximately 1/3 from the front of the seat (as
illustrated).
Supply Stop
GFCI-Protected
Receptacle
Kohler Co. 11 1054180-2-F
