6. Install the Remote Control Holder
Choose a mounting location for the remote control holder that is
easily accessible while sitting on the seat.
The remote control holder can be installed using screws or
double-sided tape. Choose your preferred method for securing
the remote control holder. Follow only the instructions for your
chosen installation method.
Install Using Screws
NOTE: Anchors may not be needed for installation to certain
materials. Use the appropriate mounting hardware for your
particular installation surface.
Position the remote control holder at the desired mounting
location with the rectangular indent toward the bottom (as
shown).
Using a pencil, mark the two mounting hole locations. Set the
holder aside.
For installation to stud or other wood surface: Drill a 1/16″ hole
at each of the marked locations.
For installation using wall anchors: Drill a 1/4″ hole at each of
the marked locations. Install the wall anchors into the holes.
Position the remote control holder over the mounting holes so the
rectangular indent is toward the bottom.
Secure the remote control holder with the screws.
Remote Holder
If used, apply tape here.
Anchors
Screws
Remote
Covers
Kohler Co. 9 1054180-2-F
