105
K
1
2
13
14
15
16
17
18
3
4
5
6
7
12
11
10
8 9
B2
J
10
4
2
6
8
9
3
1
5
7
Fig. 9.11
Fig. 9.9
Fig. 9.10
W M
B
Tab. 9.16
ED0053030410
ASSEMBLY INFORMATION
CYCLE SCREWS TORQUE
1 J - Torx M14x1,5 60 Nm
2 K - Torx M10x1.25 30 Nm
3 J - Torx M14x1,5 45°
4 J - Torx M14x1,5 45°
Important
• The fastening bolts J, K must be replaced every time they
are assembled.
• Failure to adhere to the bolt fixing procedures may
compromise the functionality of the engine, and also may
cause damage to persons and property.
• Tighten capscrews J, K observing the cycles, tightening, and
subsequent rotation as indicated in Tab. 9.2.
7 -
Apply "Molyslip AS COMPOUND 40" on the threads and
under the head of capscrews J and K and manually tighten
them until their stop.
8 -
Tightening the screws J, K strictly following the sequence
indicated in the Fig. 9.9 or Fig. 9.10 and the tightening
torque indicated in the Tab. 9.2.
9 -
Check that crankshaft M rotates smoothly.
10 -
Insert gasket W into the seat of crankcase B (ST_47).
