ASSEMBLY INFORMATION
* Alternatively to the capscrew replacements, with "Dri-loc"
* Alternatively to the capscrew replacements, with "Dri-loc"
OPTIONAL COMPONENTS (CHAP. 11)
HEATER
Component Thread (mm) Torque (Nm) Sealer
Flange intake with heater fastening capscrew M8x1.25 25
COOLING CIRCUIT
Component Thread (mm) Torque (Nm) Sealer
Blower fastening capscrew M6x1 10
Radiator support fastening capscrew (on crankcase) M12x1.75
Shroud radiator fastening capscrew M6x1 10
Radiator central brace fastening screw M10x1.5
Radiator on anti-vibrating M8x1.25 25
Vibration-damping nut xing (on radiator support) M8x1.25 25
Anti-vibrating and brace fastening capscrew (upper) M8x1.25 25
Upper brace fastening capscrew (on engine cylinder head) M8x1.25 25
Side bulkheads fastening capscrew M6x1 10
