TECHNICAL INFORMATION
2.13.3.1 Wiring disconnection
All sensor connectors and electronic control devices are sealed.
The connectors must be disconnected by means of pressure
on tabs A or unblock the retainers B, as illustrated from Fig.
2.34c to Fig. 2.34r.
