2.18 Components handling
2.18.1 High-pressure fuel injection pump
- Only handle by means of the points marked by Y.
- It is forbidden to handle using the points marked by N.
2.18.2 Electronic injector
- Only handle by means of the points marked by Y.
- It is forbidden to handle using the points marked by N.
2.18.3 Common Rail
- Only handle by means of the points marked by Y.
- It is forbidden to handle using the points marked by N.
2.18.4 Turbocharger
- Only handle by means of the points marked by Y.
- It is forbidden to handle using the points marked by N.
Important
• Refer to Par. 2.19.
