7
93
_07
Fig. 7.5
T
S
Fig. 7.7
E
F
H
G
J
Fig. 7.6
A
C
B
D
P
R
Q
Fig. 7.4
ED0053029590
INFORMATION FOR DISASSEMBLY
3 - Undo capscrews S and remove flange T with the relative
gasket.
3 -
Disconnect the connectors E, F and G.
4 - Release the clamps J and H.
7.3 Electric components disassembly
7.3.1 Electric wiring
Important
• Refer to Par. 2.13.3.1 prior to proceeding with disassembly.
1 - Disconnect the connectors A, B and C.
2 - Release the clamp D.
7.2.2 EGR Valve
1 - Disconnect the connector P.
2 - Undo the screws Q and remove the EGR valve R with the
relevant gasket.
NOTE: The EGR valve is not a serviceable item, and if
damaged/worn, it should be replaced with a new one.
