Kohler KG100

TP-6694 6/22 107
Figure 50 Engine Electrical System Single Starter Motor Typical Battery Connection
Figure 51 24-Volt Engine Electrical System Dual Starter Motors Typical Battery Connections
2
1
1
2
2
1
EZ-273000-J
1 To positive (+) terminal on
starter solenoid.
2 To ground (-) terminal on
or near starter motor.
2
1
2
2
2
2
1
1
1
1
12-Volt
24-Volt
KW-272000-B
1
2
1
2
1
2
1 To positive (+) terminal on
starter solenoid.
2 To ground (-) terminal on
or near starter motor.
2
1
