Kohler KPC 1000 User Manual

TT-1625 7/17 35
Connection Type
Controller Step Operation Manual Other Information
EPS Supplying Load 6.8 ATS emergency aux. contact connections
Remote
(Generator Set)
APM802 6.10 TP--7070 Wiring diagram for the respective generator
set
(Local) hardwired
Decision-Makerr 3+
6.9 TP-6161 (Industrial) or TP-6441
(Marine)
Wiring diagram for the respective generator
set
Remote
(Generator Set)
Decision-Makerr 550
6.11 TP-6200 (Industrial) or TP-6441
(Marine)
Wiring diagram for the respective generator
set
(Local) hardwired
Decision-Makerr 3000
6.9 TP-6694 Wiring diagram for the respective generator
set
(Local) hardwired
Decision-Makerr 3500
6.9 TP-6914 (Industrial) or TP-6861
(Marine)
Wiring diagram for the respective generator
set
Remote
(Generator Set)
Decision-Makerr 6000
6.11 TP-6750 Wiring diagram for the respective generator
set
Remote
(Generator Set)
Decision-Makerr 8000
6.12 TP-6990 Wiring diagram for the respective generator
set
(Local) hardwired KPC 1000 6.9 TP-6427 and TP-6471 (Software) Wiring diagram for the respective generator
set
Remote (ATS)
MPACr 1000
6.9 TP-6126 Model KCT/KCP ATS
Remote (ATS)
MPACr 1500
6.9
TP-6714
Model KCS/KCP/KCC/KBS/KBP/KBC/KGS/
KGP/KSS/KSP/KEP ATS
Remote (ATS)
Decision-Makerr
MPACr 750
6.9 TP-6865 Model KSS ATS
Remote (ATS)
Decision-Makerr
MPACr 1200
6.9 TP-6866 Model KCS/KCP/KCC/KSS/KSP ATS
Remote (ATS)
Decision-Makerr
MPACr 1500
6.9 TP-6883 Model KCS/KCP/KCC/KBS/KBP/KBC/KGS/
KGP/KEP ATS
Figure 56 Product Connection Input Instructions
