3
Kohler Co., Kohler, WI U.S.A.
1007275-2-
A
Drill a 1/4” mounting hole at the
mark on the floor, then drill two 1/4”
hanger bolt holes at the marks on
the wall.
Mount hanger bolts to the wall so
approximately 1-1/4” (3.2cm) of
each bolt remains exposed.
NOTE: Other fastening devices of
sufficient size and strength may also be
used.
Finish Wall
Hanger
Bolts
Install the faucet and drain to the
lavatory according to the
manufacturer’s instructions.
NOTE: Do not fully tighten slip-joint
drain connections at this time.
Position the pedestal mounting hole
over the hole in the floor.
Secure the pedestal to the floor with
the wood screw and washer. Tighten
the wood screw until it is snug.
CAUTION: Risk of product
damage. Do not overtighten.
Overtightening may cause damage to
the product.
Pedestal
Wood Screw
Washer
To Next Page
