Kohler MEMOIRS User Manual

-2-
ROUGHING-IN
Unit: mm
PARTS IDENTIFICATIONPARTS IDENTIFICATION
BCHSKU
H
B
C
K-36938T
K-36952T
K-36945T
K-36959T
800-1200 800-1200 1850-2000
K-36938T/K-36945T
MEMOIRS Bracket Assy
X2
MEMOIRS Handle Assy
MEMOIRS Wall Clip Assy
X4
MEMOIRS 135 DEG Hinge Assy
135 X2
MEMOIRS Bottom Clip Assy
X2
MEMOIRS Wall Clip Body Cover
X4
Special Key
X1
Cover
X8
4mm Allen Key
4mm
X5
X5
X2
Hinge Cover
X10
SINGULIER
Bracket Assy
X2
SINGULIER Handle Assy
SINGULIER Wall Clip Assy
X4
SINGULIER 135 DEG Hinge Assy
135 X2
SINGULIER Bottom Clip Assy
X2
SINGULIER Wall Clip Body Cover
X4
Frame Cap, 135 LH
()X1
°
135°
Frame Cap, 135 LH
()X1
°
135°
Frame Cap, 135 RH
()X1
°
135°
Frame Cap, 135 RH
()X1
°
135°
Special Key
X1
Cover
X8
4mm Allen Key
4mm
X5
X5
X2
Hinge Cover
X10
K-36952T/K-36959T
1146426-T01-B

Kohler MEMOIRS Specifications

General

Brand	Kohler
Category	Shower Cabins
Collection	MEMOIRS
Finish	White
Drain Placement	Center
ADA Compliant	Yes
Warranty	One-Year Limited Warranty
