Kohler PERSUADE User Manual

1102602-A2-D 4 KohlerCo.
4 Bracket
Drill 3/8” (10 mm) xing holes at the marked locations on the oor and insert
the anchor. Install the washer and insert the hexagon screw into the bracket
then tighten the screw. Position the toilet in the installed position. Install the
sleeves, tighten the screw and aach the caps.
Floor xing option
5 Screw
Drill 5/16” (8 mm) mounting holes at the marked locations. Insert anchors into
the holes. Place the toilet and align with anchoring holes position. Tighten screws
and aach the bolt caps.
Anchor
Screw
Sleeve
Hole
Cap
Hexagon
Lag Screw
Bracket
Washer
Anchor
Fixing Holes
Screw Cap
Screw
Anchor
Sleeve
Drill

Kohler PERSUADE Specifications

General

Bowl Shape	Elongated
Material	Vitreous China
WaterSense Certified	Yes
ADA Compliant	Yes
Flush Type	Gravity
Water Consumption	1.28 GPF
Rough-In	12 inches
Color Options	White, Biscuit, Black
