TP-6881 7/15 65Section 4 Troubleshooting
Status Message CheckDescription/ CommentsAction
Load Shed 1 Status Info [ Notice The digital output for LoadPriority1Shed
is active (contacts closed), indicating the
1st priority load shed (load management
device) has been activated.
Remove loads as required.
Check building wiring for
proper load distribution.
Check engine fuel supply.
Load Shed 2 Status Info [ Notice The digital output for LoadPriority2Shed
is active (contacts closed), indicating the
2nd priority 1st priority load shed (load
management device) has been activated.
Remove loads as required.
Check building wiring for
proper load distribution.
Check engine fuel supply.
Load Shed 3 Status Info [ Notice The digital output for LoadPriority3Shed
is active (contacts closed), indicating the
3rd priority 1st priority load shed (load
management device) has been activated.
Remove loads as required.
Check building wiring for
proper load distribution.
Check engine fuel supply.
Load Shed 4 Status Info [ Notice The digital output for LoadPriority4Shed
is active (contacts closed), indicating the
4th priority 1st priority load shed (load
management device) has been activated.
Remove loads as required.
Check building wiring for
proper load distribution.
Check engine fuel supply.
Load Shed 5 Status Info [ Notice The digital output for LoadPriority5Shed
is active (contacts closed), indicating the
5th priority 1st priority load shed (load
management device) has been activated.
Remove loads as required.
Check building wiring for
proper load distribution.
Check engine fuel supply.
Load Shed 6 Status Info [ Notice The digital output for LoadPriority6Shed
is active (contacts closed), indicating the
6th priority 1st priority load shed (load
management device) has been activated.
Remove loads as required.
Check building wiring for
proper load distribution.
Check engine fuel supply.
* Programmable Interface Module (PIM) required.
[ Load management device required (LCM, load shed kit, or RXT with combined interface/ load management board).
Figure 4-5 Status Messages Displayed on the RDC2 Controller
