AUTONOMOUS POOL ROBOT
USER MANUAL
ROBOT DE PISCINE AUTONOME
MANUEL D’UTILISATION
ROBOT DE PISCINA AUTOMÁTICO
MANUAL DE USUARIO
AUTOMATISCHE ZWEMBADREINIGER
HANDLEIDING
ROBOT DA PISCINA AUTOMATICO
MANUALE DELL'UTENTE
AUTONOMER POOL-ROBOTER
BEDIENUNGSANLEITUNG

Table of Contents

Questions and Answers

  • P
    Paul PayneAug 18, 2025
    What to do if Kokido Swimming Pool Vacuum cannot be charged?
    • D
      Devin SpencerAug 18, 2025
      If your Kokido Swimming Pool Vacuum cannot be charged or recharged, the battery may be damaged; contact your dealer for battery replacement and do not attempt to replace the battery yourself. Also, ensure that the charging cable is completely connected with the external adapter and the robot. If the external adapter is out of order, contact your dealer for a replacement, as using the wrong adapter can damage the robot and void the warranty.
  • J
    juliaboltonAug 20, 2025
    Why is debris leaking from the filter cover of my Kokido Swimming Pool Vacuum?
    • H
      Heather ScottAug 21, 2025
      If debris leaks outside at the filter cover of your Kokido Swimming Pool Vacuum, the filter cover net is likely damaged. Replace it with a new filter cover, contacting your dealer for replacement parts.
  • J
    Jacob MartinAug 23, 2025
    Why is my Kokido Delta 200 Swimming Pool Vacuum not picking up debris?
    • K
      Kayla LopezAug 23, 2025
      If your Kokido Swimming Pool Vacuum isn't picking up debris, it could be due to several reasons. First, the battery might be low, so try charging it again. Another cause may be that the debris compartment is full, so you should clean both the debris compartment and the filter cover. Also, the suction mouth could be clogged; clear any obstructions from it. The impeller might also be jammed; in this case, power off the robot and inspect the hole under the swivel head for any large debris. If the impeller is broken, contact your dealer for a replacement.
  • U
    ucolonAug 26, 2025
    Why doesn't my Kokido Delta 200 Swimming Pool Vacuum cover the entire pool?
    • N
      nmoralesAug 26, 2025
      If your Kokido Swimming Pool Vacuum isn't covering the entire pool, several factors could be at play. Start by cleaning the debris compartment. If that doesn't solve the issue, the filter compartment may need cleaning, and the robot should be recharged for 6 hours. Also, water circulation from the filtration system could be interfering, so turn off the filtration system at least 15 minutes before operating the robot. Check the wheel for any obstructions and remove any debris. Ensure the locking pin is properly set according to the instructions. Algae can also make the pool floor slippery, causing the robot to go in circles, so scrub the pool bottom and robot wheels to remove any algae.
  • T
    Thomas MartinAug 28, 2025
    Why is my Kokido Delta 200 Swimming Pool Vacuum moving slowly?
    • S
      Stephanie ShepherdAug 28, 2025
      If your Kokido Swimming Pool Vacuum is moving slowly or not at all, it could be due to a few reasons. Check if the debris compartment is full or if the filter cover is clogged, and clean the debris compartment, flushing the screen with water. If necessary, use a soft brush to gently clean the screen, ensuring the filter cover is in place before the next use. Also, the suction mouth could be clogged, so remove any obstructions. The impeller may be jammed as well; power off the robot and inspect the hole under the swivel head for any large debris. If needed, contact your dealer for further assistance.
  • M
    Matthew CalhounAug 30, 2025
    What to do if Kokido Swimming Pool Vacuum stops in the middle of the pool?
    • A
      Angela BakerAug 30, 2025
      If your Kokido Swimming Pool Vacuum stops moving in the middle of the pool but the swivel head is still turning, it could be due to an obstruction or large creases in the pool liner; check for anything blocking the cleaner and remove it. Alternatively, the robot might be stopped by suction from the main drain of the pool floor; in this case, turn off the filtration system as instructed in the manual.
  • J
    Jennifer SmithSep 2, 2025
    Why is the swivel head on my Kokido Delta 200 Swimming Pool Vacuum not turning?
    • E
      Elizabeth GarciaSep 2, 2025
      If your Kokido Swimming Pool Vacuum's swivel head does not turn or turns noticeably slowly, start by checking and removing any debris that hinders the movement of the side flap. Also, ensure that the two floats are on the flap. The swivel head bottom might be jammed; detach the swivel head and smoothening-ring, then remove any trapped debris, verify the smooth-ring and bottom plate are installed correctly, and inspect the smoothening-ring for potential damage, replacing it if necessary.
  • N
    nshahSep 4, 2025
    How to stop Kokido Swimming Pool Vacuum from moving along the pool wall?
    • B
      bbrownSep 4, 2025
      If your Kokido Swimming Pool Vacuum is moving along the pool wall, it might be because the locking pin is not set properly or the robot was facing the wrong direction at the beginning. Follow the instructions to adjust the locking pin setting and ensure that the robot’s front/back faces the pool wall at the start.
  • A
    Andrew AdamsSep 6, 2025
    Why is debris escaping from my Kokido Swimming Pool Vacuum?
    • S
      starkdouglasSep 6, 2025
      If debris is escaping from your Kokido Swimming Pool Vacuum, it could be because the suction mouth’s flap at the cleaner bottom is damaged; contact your dealer for replacement parts and instructions. Alternatively, debris might be clogged at the suction mouth, preventing the flap from closing; remove any clogged debris from the suction mouth.
  • K
    Kevin ReedSep 9, 2025
    Why does the swivel head on my Kokido Delta 200 rotate repeatedly?
    • J
      Jennifer RangelSep 9, 2025
      If your Kokido Swimming Pool Vacuum's swivel head rotates repeatedly, it could be due to air trapped inside the robot. The swivel head may rotate repeatedly for a few minutes once the robot sinks to the pool bottom. This should stop once the air is gradually discharged, and the robot will begin to move regularly.

Summary

SAFETY WARNINGS & INSTRUCTIONS

HOW THE ROBOT WORKS

GETTING STARTED

Charging The Battery

Detailed steps for charging the robot, including initial charge time and indicator lights.

Set-Up Before Use

Covers initial robot setup, including trajectory adjustment and locking pin configuration.

Pool Preparation

Essential steps for preparing the pool environment, including checking for debris and ensuring proper water conditions.

OPERATION

EMPTYING THE DEBRIS COMPARTMENT

Step-by-step guide on how to safely open and clean the robot's debris compartment and filter.

Float Replacement

Instructions for replacing the robot's float using basic tools and following specific steps.

Flap replacement

Procedure for replacing the robot's side flap, including visual guides for the steps involved.

MAINTENANCE & STORAGE

Guidelines for proper storage of the robot, including battery care and environmental conditions.

BATTERY DISPOSAL

Instructions and warnings regarding the safe disposal and recycling of the robot's lithium-ion battery pack.

TROUBLESHOOTING

Kokido Delta 200 Specifications

General IconGeneral
BrandKokido
ModelDelta 200
CategorySwimming Pool Vacuum
LanguageEnglish
