Kokido xtrovac 710 - User Manual

Questions and Answers

N
Natasha HendersonAug 13, 2025
What to do if Kokido xtrovac 710 does not capture debris?
- M
  Mrs. Valerie Singh DVMAug 13, 2025
  If your Kokido Swimming Pool Vacuum isn't picking up debris, several factors could be at play: * The battery might be low, requiring a recharge. * The impeller might be jammed; in that case, power off the vacuum and check the gap in the middle of the vacuum to see if the impeller is blocked. If possible, carefully remove any debris with a small tool. Contact your dealer if needed. Warning! Make sure the pool vacuum is powered off when servicing. * The impeller might be broken, requiring a replacement from your dealer. * The canister could be full, so empty it. * The cartridge filter might not be in the correct position; shift it to the NORMAL position or detach it.
N
Nicole HansonAug 16, 2025
Why Kokido xtrovac 710 Swimming Pool Vacuum cannot be charged / recharged?
- A
  Angela BallAug 17, 2025
  If your Kokido Swimming Pool Vacuum isn't charging, it could be due to several reasons: * The battery might be damaged, requiring replacement by a dealer. Warning! Do not attempt to open the pool vacuum and replace the battery yourself, as this could result in injury and will void the warranty. * The charging plug may not be correctly connected to the external adapter and pool vacuum. Refer to the instruction manual for proper connection. * The external adapter might be damaged, requiring replacement by a dealer. Warning! Using the wrong external adapter can damage the pool vacuum/battery and void the warranty.
C
christophergreenAug 21, 2025
What to do if fine debris escapes from Kokido xtrovac 710 Swimming Pool Vacuum?
- A
  awalkerAug 21, 2025
  If fine debris is escaping from your Kokido Swimming Pool Vacuum, ensure that the cartridge filter is in the FINE position. If the issue persists, the cartridge filter may be broken and require replacement.
D
dbooneAug 25, 2025
Why operation time of Kokido xtrovac 710 Swimming Pool Vacuum is shorter as expected?
- M
  Morgan WilsonAug 25, 2025
  If the operation time of your Kokido Swimming Pool Vacuum is shorter than expected, ensure that the battery is fully charged by charging the pool vacuum for at least 6 hours. Note: If any stains are found on the charging pins, remove them using a cotton bud soaked with lemon juice or vinegar.
T
Tommy HolmesAug 28, 2025
What to do if debris escapes from the canister of Kokido xtrovac 710?
- S
  simmonstinaAug 28, 2025
  If debris is escaping from the canister of your Kokido Swimming Pool Vacuum, it could be because the suction nozzle flap is broken. The suction nozzle flap prevents debris from escaping from the canister, so replace it with a new one. Alternatively, the filter net of the water draining valve might be broken, in which case you should replace it with a new filter net.
Q
qflynnSep 1, 2025
Why charging time of Kokido xtrovac 710 is longer than advertised?
- E
  Elizabeth MurraySep 1, 2025
  If the charging time of your Kokido Swimming Pool Vacuum is longer than advertised, the charging pins may be stained. Remove the stains by using a cotton bud soaked with juice of lemon or vinegar to clean the areas around the charging pins.
C
Christina CookSep 4, 2025
What to do if debris goes side the filter cone in Kokido Swimming Pool Vacuum?
- J
  jillyoungSep 4, 2025
  If debris goes to the side of the filter cone in your Kokido Swimming Pool Vacuum, the filter cone is damaged and needs to be replaced with a new one.
T
Tracy TorresSep 8, 2025
How to fix telescopic pole connector that cannot be secured in Kokido xtrovac 710 Swimming Pool Vacuum?
- H
  hphillipsSep 8, 2025
  If the telescopic pole connector cannot be secured in your Kokido Swimming Pool Vacuum, the side pin on the pole connector is likely broken and needs to be replaced with a new pole connector.

Summary

Safety Warnings & Instructions

Save These Instructions

Instructions to keep for future reference regarding product safety.

Warning!

Critical safety alerts and precautions for product operation and child safety.

Getting Started

Charging the Battery

Detailed steps and important notes for charging the pool vacuum battery.

Set-Up Before Use

Telescopic Pole Assembly

Instructions for assembling the telescopic pole for EU & USA models.

Specific Telescopic Pole Assembly

Instructions for assembling the telescopic pole for Australia & New Zealand models.

Operation

Warning!

Critical safety warnings during pool vacuum operation.

Cleaning the Filter

Warning!

Warning regarding filter usage and warranty.

Maintenance & Storage

Warning!

Warning against disassembling the pool vacuum.

Caution!

Cautions regarding battery health and replacement.

Battery Disposal

Warning!

Warnings for safe battery removal and handling.

Caution!

Precautions for handling leaking battery fluids.

How to Remove the Battery Pack

The Kokido Xtovac 710 is a pool vacuum cleaner designed for underwater use in pools and spas. It is a handheld, rechargeable, and cordless device, offering flexibility and ease of use for cleaning various types of debris.

Function Description:

The primary function of the Xtovac 710 is to clean pools and spas by vacuuming debris from the water. It is equipped with a filter system to capture both normal and fine debris like sand and fine dust. The device operates underwater and is powered by a rechargeable lithium-ion battery.

Important Technical Specifications:

Maximum Operating Depth: 3 meters (9.8 ft)
Maximum Water Temperature: 5°C (41°F) – 35°C (95°F)
Battery Type: Rechargeable Lithium-Ion battery pack
Charging Time: Approximately 5-6 hours for a full charge
Operating Time (on full charge): Up to 75 minutes
Charging Unit: Detachable external adaptor (model numbers: DSS12D-1351000-B / DSS12D-1351000-C / DSS12D-1351000-D/ LX135100U)
Filter System: Cartridge filter with NORMAL and FINE settings

Usage Features:

Cordless Operation: The Xtovac 710 is a cordless vacuum, providing unrestricted movement during cleaning.
Telescopic Pole Compatibility: It can be attached to a telescopic pole (not included) for extended reach, with specific assembly instructions for EU/USA and Australia/New Zealand models.
Filter Settings: The cartridge filter can be set to a "NORMAL" position for general cleaning or removed entirely to prolong its life. For fine filtration, it can be set to a "FINE" position to pick up small debris like sand and fine dust.
Power On/Off/Charging Mode: A switching knob allows users to turn the device on, off, or set it to charging mode.
Battery Indicator Lights: The device features indicator lights to show the remaining battery charge. Four lights indicate up to 75 minutes of operation, while a blinking last light indicates 10-15 minutes of usage remaining.
Underwater Operation: The vacuum must be fully immersed in water before operation to prevent damage and voiding the warranty. The minimum water level must cover the entire unit.
Saltwater Pool Compatibility: Can be used in saltwater pools, provided all salt is dissolved before deployment.
Draining Mechanism: When removed from the pool, the device drains water through the pole, a draining valve on the canister, and the bottom of the vacuum.
Safety Precautions:
- Not a toy; keep out of reach of children.
- Not intended for use by persons with reduced physical, sensory, or mental capabilities without supervision.
- Do not operate with people or pets in the water.
- Do not use without an intact filter cone.
- Avoid suction entrapment by keeping hair, body, and loose clothing away from the suction hole.
- Do not insert body parts or objects into openings and moving parts.
- Do not use to pick up toxic, flammable, or combustible liquids.
- Do not attempt to disassemble or replace impeller, motor, or battery yourself.
- Do not handle with wet hands while charging.
- Do not use immediately after pool-shocking; wait 24-48 hours.
- Avoid picking up hard, sharp objects.
- Do not use simultaneously with other automatic cleaners.
- Ensure charging cable is detached before deployment.
- Always face the vacuum downwards when placing into or removing from the pool to prevent damage to the pole connector.

Maintenance Features:

Filter Cleaning: The cartridge filter and filter cone should be cleaned before and after each use to maximize cleaning efficiency. The filter cone can be detached by releasing latches and turning it anticlockwise. Debris should be cleaned, and the filter cone rinsed with water. A soft brush can be used for stubborn dirt.
Cartridge Filter Replacement: Inspect the cartridge filter regularly for damage or tears and replace if necessary.
Charging Port and Pins Cleaning: After every use, clean and dry the charging port and pins to prevent stains. Stains can be removed with a cotton bud soaked in lemon juice or vinegar.
Storage:
- Store indoors in a clean, dry, well-ventilated area away from sunlight, heat, ignition sources, pool chemicals, and children.
- Ambient storage temperature should be 10°C – 25°C (50°F – 77°F).
- Charge the battery to 30%-50% capacity before storing for extended periods.
- Recharge the battery at least once every three months when not in use.
- Do not leave the pool vacuum plugged in for long-term storage.
- Ensure the pool vacuum and charging plug are completely dry before charging.
- Disconnect the external adaptor from the power source and the charging plug when not in use.
Battery Disposal: The built-in rechargeable lithium-ion battery pack must be removed by a skilled technician for proper disposal and recycling, in accordance with local ordinances. Users are warned not to attempt battery disassembly themselves due to safety risks (short circuit, burns, explosion).
General Cleaning: Rinse the pool vacuum with fresh water after every use; do not use detergent. Use a damp cloth to clean and dry the unit and accessories.
Troubleshooting: The manual provides a troubleshooting guide for common issues such as failure to capture debris, debris escaping, charging problems, and reduced operation time.
