Kolin Quad Series - Air Direction Adjustment

- 12 -
Air direction adjustment
Remote
control
panel
Air inlet
louver
Cabinet
Front intake
grille
(behind the
front intake
grille)
Panel outlook picture, just for reference, please take the real unit as standard.
Horizontal Louver
upwards, downwards or straight out.
positioning manually the louver to discharge the air
The Horizontal Louver is controlled by
