C
HAPTER
3 - O
PERATION
BDS
3-2
(motor shaft turns in the wrong direction),
remove power.
2. Reverse the input to the BDS4 at DIFF CMD
HI and DIFF CMD LO at Connector C1, Pins 1
and 11.
DO NOT ATTEMPT TO
REVERSE DIRECTION OF ROTATION
BY INTERCHANGING MOTOR LEADS
AND/OR RESOLVER LEADS.
NOTE
If the motor is commanded to
move and does not respond,
turn the command scale
adjustment several turns CW.
If the servo system performed properly, then read
Chapter 4 - Maintenance for adjustments and other
information that may be helpful in adapting your
system to your own applications.
