Kollmorgen BDS4 Series

C
HAPTER
6 - S
PARE
P
ARTS
BDS
4
6-2
Table 6.2. PSR4/5 Spare Parts List
DESCRIPTION
PSR4/5
MODEL PART NO.
QUANTITY
PER UNIT
CONNECTOR KIT ALL
12 AND 20A
PSR4/5C-100 1
CONNECTOR KIT ALL
50 AND 75A
PSR4/5C-200 1
CONTROL VOLTS
FUSES
ALL
12 AND 20A
A-78896-008 (1.5 AMP)
FUSE 99, 102
2
A-78896-012 (4 AMP)
FUSE 126
1
CONTROL VOLTS
USES
ALL 50 AND
75A
A-78896-012 (4 AMP)
FUSE 64,65
2
A-78896-016 (8 AMP)
FUSE 24
1
SOFT-START
FUSE
115 VAC
12 AND 20 AMP
A-80552-007 (5 AMP)
FUSE 121
1
SOFT START
FUSE
ALL 230 VAC
12 and 20 AMP
A-80552-001 (10 AMP)
FUSE 121
1
SOFT-START
FUSE
ALL 50 AND 75 AMP A-78896-017 (10 AMP)
IN-LINE
1
REGEN FUSE -112, 120 A-80552-013 (7 AMP)
FUSE 132
1
REGEN FUSE -112-02
-120-02
A-80552-001 (10 AMP)
FUSE 132
1
REGEN FUSE -212, 220 A-80552-009 (8 AMP)
FUSE 132
1
REGEN FUSE -212-01, -220-01 A-80552-002 (12 AMP)
FUSE 132
1
REGEN FUSE 220-03 A-80552-003 (15 AMP)
FUSE 132
1
CAUTION
ALL FUSES MUST BE REPLACED WITH EXACT SAME VALUE AND STYLE OR THEY
WILL NOT BE EFFECTIVE.
