DS4 A
PPENDIX
B - M
ODEL
N
UMBER
B-1
A
PPENDIX
B
M
ODEL
N
UMBERS
Table B.1. PSR4/5 Model Number Scheme
EXAMPLE: PSR
4/5A- 2 50- XX* YY*
LEGEND: A B C D E F
LEGEND DEFINITION
A Power Supply with Regeneration (shunt regulation) and soft-start.
B Power Supply generation indicator.
4/5 Standard Configuration. Used with BDS4 series servo motor amplifiers.
4/5V Industrial Standard Configuration
4/5A U.L. 508 listed Configuration. Used with BDS4A series servo motor amplifiers.
C AC Line Voltage (L-L) RMS.
1 115 VAC, Single-Phase (not available for 50 and 75 amp models).
2 220 VAC, Single-Phase or 230 VAC, Three-Phase.
D 12,20,50,75 AC Line Current, RMS.
E Mechanical Options.
00 Standard - No Option (all models have side cover)
01 Use "00" for new applications (previously with side cover).
70 Custom.
71 Custom.
72 Custom.
73 Custom.
80 Custom.
91 Special (12 and 20 amp PSR4/5 units only, with cover, without connector kit, 2 axes maximum).
F Electrical Options.
00 Standard. No Options. 12 and 20 Amp models contain 40 Watt Internal Regeneration Resistor. 50
and 75 Amp Models require Regeneration Resistor Kit EX-2X (must be ordered separately).
01 8.8 Ohms, 400 Watt External Regen, 230 Volt, 12 and 20 Amp Models Only. Requires ER-01
External Resistor Kit.
02 5.5 Ohms, 200 Watt, 115 Volt External Regen, 12 and 20 Amp Models Only. Requires ER-02
External Resistor Kit.
03 5.8 Ohms, 700 Watt, 230 Volt External Regen, 12 and 20 Amp Models Only. Requires ER-03
External Resistor Kit.
20 Custom.
50 Without Soft-Start (50 and 75 Amp Models Only). Requires ER-2X External Resistor Kit.
70 Without Soft-Start and Regeneration (12 and 20 Amp Models Only).
80 Without Regeneration (12 and 20 Amp Models Only).
81 With 240 V logic supply unit, withou regen, with soft-start.
*XXYY - Omit when there are no options.
