21) Torq min – Minimum torque: The minimum torque and maximum torque options allow the user to set
the acceptable torque range for each single application. When the reached torque is inside this range,
“tightening OK” will be displayed on the status bar and the green led will light up. If the reached torque is
outside this range the messages “error minimum torque” or “error maximum torque” will be displayed. You
can set the torque range from 0 to 40 Nm at intervals of 0.01 Nm.
The minimum torque option allows to set the lowest value of the torque range and it’s on if calibration is 'ON'.
If calibration is 'OFF' the minimum torque value automatically sets on 0 Nm.
22) Torq Max – Maximum Torque: The minimum torque and maximum torque options allow the user to
set the acceptable torque range for the single application. When the reached torque is inside this range, “right
screwing” will be displayed on the status bar and the green led will light up. The messages “below minimum
torque” or “over maximum torque” will be displayed if the reached torque is outside this range. You can set
the torque range from 0 to 55 Nm at intervals of 0.01 Nm.
The maximum torque option allows to set the highest value of the torque range and it’s on if the calibration is
'ON'.
23) Func T&A–T&A function mode: You can activate the Torque & Angle function. Set OFF when you
don’t need this function. When you set ON you can choose among six working conditions (see T&A specific
instructions).
-
-
-
-
-
-
-
-
M
E
N
U
-
-
-
-
-
-
-
-
2
4
)
S
t
a
r
t
i
n
g
T
o
r
:
-
-
-

2
5
)
A
n
g
.
m
i
n
:
-
-
-
2
6
)
A
n
g
.
m
a
x
:
-
-
-
24) Starting Tor – Starting torque: If T&A option is set on Tor mode (See T&A paragraph), you can set
the torque threshold the angle starts to be read from. When T&A is set on angle mode (see T&A paragraph),
you can set the torque threshold the angle starts to be carried out from.
In # mode, the torque threshold must be included in the range of values relating to the pre-set speed and model.
25) Ang. min – Minimum angle: Minimum angle threshold. You can set it when T&A is set on Tor, T/in or
T/lv (see T&A specific instructions). The minimum angle the operator can set is 5°.
26) Ang. max - Maximum angle: Maximum angle threshold. You can set it when T&A is set on Tor, T/in
or T/lv (see T&A specific instructions). The maximum angle the operator can set is 29999°.
When T&A is set on Ang., A/in or A/lv mode, maximum angle corresponds to the angle that has to be carried
out.
