METHOD FOR CLEANING POWER TRAIN CASE BREATHER
1.
Remove bolts (1) of step.
2.
Remove step (2).
3.
Remove bolts (3).
4.
Remove cover (4).
5.
Remove breather (5).
6.
Rinse breather (5) in clean diesel fuel or flushing oil, and
remove dirt from inside.
METHOD FOR REPLACING HYDRAULIC TANK BREATHER ELEMENT
NOTICE
Note that the fuel tank breather and hydraulic tank breather have different part numbers.
(The element is common to both. See “CONSUMABLE PARTS (7-3)”.)
1.
Remove nut (2) of breather assembly (1) on the top of the
hydraulic tank.
2.
Remove cover (3).
3.
Replace breather element (4) with a new one.
4.
Install cover (3) and nut (2).
Tightening torque: 10 to 14 Nm {1.0 to 1.4 kgm, 7.2 to
10.1 lbft}
MAINTENANCE MAINTENANCE PROCEDURE
4-77
