Working ranges Unit PC200-8 PC200LC-8 PC220-8 PC220LC-8
A Max. digging reach mm (ft in) 9,875 (32' 5") 9,875 (32' 5") 10,180 (33' 5") 10,180 (33' 5")
B Max. digging depth mm (ft in) 6,620 (21' 9") 6,620 (21' 9") 6,920 (22' 8") 6,920 (22' 8")
C Max. digging height mm (ft in) 10,000 (32' 10") 10,000 (32' 10") 10,000 (32' 10") 10,000 (32' 10")
D Max. vertical wall depth mm (ft in) 5,980 (19' 7") 5,980 (19' 7") 6,010 (19' 9") 6,010 (19' 9")
E Max. dumping height mm (ft in) 7,110 (23' 4") 7,110 (23' 4") 7,035 (23' 1") 7,035 (23' 1")
F Min. dumping height mm (ft in) 2,645 (8' 8") 2,645 (8' 8") 2,530 (8' 4") 2,530 (8' 4")
G
Max. digging reached at
ground level
mm (ft in) 9,700 (31' 10") 9,700 (31' 10") 9,700 (31' 10") 9,700 (31' 10")
5 - 3
