OPERATION
TRANSPORTATION
LIFTING PROCEDURE
Lifting work can be carried out only for machines with lifting marks. Before starting the lifting operation, stop the
machine in a horizontal place and do as follows.
1. Start the engine, set the machine facing directly to the front,
place the dump lever at the FLOAT position, and check that the
dump body pilot lamp goes out.
2.
Stop the engine, check that the area around the operator's
compartment is safe, then lock with the articulation lock so that
the front frame and rear frame cannot bend.
3.
To prevent damage to front grill (1) during lifting operations,
remove front grill (1) before starting.
4. Fit the lifting equipment to the lifting hooks (with the lifting mark)
at the front of the front frame and the rear of the rear frame. To
prevent damage to the lifting equipment, put protective
material between the body and the lifting equipment at contact
points (2).
5.
When the machine leaves the ground, stop for a moment and
wait for the machine to stabilize, then continue the lifting
operation slowly.
3 - 114
