200 General Information on troubleshooting
Connector list and layout
40-200 14 PC200, 200LC, 220, 220LC-8M0
SEN06132-01
Connector list and layout
Connector No. Model
Num-
ber of
pins
Component name
Address of
stereogram
A13 DT 2 Intermediate connector H-1
A15 DT 2 Intermediate connector K-9
A40 DT 4 Intermediate connector S-1
A41 DT 4 Camera 2 S-1
AB Terminal 1 Alternator (Terminal B) AG-9
AC01 10 Air conditioner unit X-5
AC02 4 Air conditioner unit W-9
AC03 X 1 Air conditioner compressor electromagnetic clutch AF-4
AMB AIR
PRESSURE
FRAMATOME 3 Ambient pressure sensor AE-2
BOOST PRESS.
&IMT
SUMITOMO 4 Boost pressure/temperature sensor intake manifold AG-5
CAM SENSOR FRAMATOME 3 Engine Bkup speed sensor AF-1
C01 AMP 80 Pump controller V-9
C02 AMP 40 Pump controller W-9
CE01 DRC 60 Engine controller AG-1
CE02 DRC 50 Engine controller AF-1
CE03 DTP 4 Engine controller AG-1
CK01 070 18 KOMTRAX communication module X-7
CK02 070 12 KOMTRAX communication module X-7
CM01 070 18 Machine monitor O-5
CM02 070 12 Machine monitor O-5
CM04 070 8 Machine monitor O-5
COOLANT TEMP PACKARD 2 Engine coolant temperature sensor AE-3
CP3 PUMP
REGULATOR
80SCH 2 Pump regulator valve AJ-2
CRANK SENSOR FRAMATOME 3 Engine Ne speed sensor AF-1
D01 SWP 8 Diode N-9
D02 SWP 8 Diode N-9
D03 SWP 8 Diode N-9
D10 M 2 Diode
D11 M 2 Diode
E01 Terminal 1 Electrical intake air heater AG-5
E06 DT 2 Intermediate connector AI-1
E08 X 1 Intermediate connector AG-9
E10 D 1 Intermediate connector AE-6
E12 3 Alternator (Terminals IG and L) AH-8
F01 Terminal 20 Fuse box T-9
F04 L 2 Fusible link (65A) B-9
F05 M 2 Fusible link (30A) C-8
FUEL RAIL
PRESS
BOSCH 3 Common rail pressure sensor AI-5
H09 M 8 Intermediate connector X-4
H15 090 22 Intermediate connector V-1
