305 Troubleshooting by failure code, Part 5
Failure code [DXE5KA] Merge-divide Main Sol Open Circuit
40-305 32 PC200, 200LC, 220, 220LC-8M0
SEN06137-00
Failure code [DXE5KA] Merge-divide Main Sol Open Circuit
Action
level
Failure code
Failure
Merge-divide Main Solenoid Open Circuit
(Pump controller system)
L01 DXE5KA
Detail of failure
q When pump merge-divider (main) EPC solenoid is driven, no current flows and open circuit is de-
tected .
Action of con-
troller
q None in particular (Since no current flows, merge-divider main solenoid does not operate. Since no
current flows, merge-divider LS solenoid does not operate, either.)
q Even if cause of failure disappears, machine does not become normal until starting switch is turned
to OFF position.
Problem on
machine
q Single operation speed of work equipment and swing is high in fine control mode (L).
q Machine does not turn easily during travel.
Related infor-
mation
q Drive current to merge-divider main EPC solenoid can be checked with monitoring function.
(Code: 08000 Merge-divider (main) solenoid current)
q Method of reproducing failure code: Turn starting switch to ON position.
Cause Procedure, measuring location, criteria and remarks
1
Defective merge-divider main EPC
solenoid (internal open circuit)
1. Turn starting switch to OFF position.
2. Disconnect connector V23, and connect T-adapters to male side.
Between V23 (male) (1) and (2) Resistance 3 to 14 z
2
Open or short circuit in wiring har-
ness
1. Turn starting switch to OFF position.
2. Disconnect connector C02 and connect T-adapters to female side.
Between C02 (female) (112) and each of (115),
(117) and (120)
Resistance 3 to 14 z
3
Open circuit in wiring harness
(wire breakage or defective con-
tact of connector)
a If no failure is found by check on cause 2, this check is not required.
1. Turn starting switch to OFF position.
2. Disconnect connectors C02 and V23, and connect T-adapters to each
female side.
Between C02 (female) (112) and V23 (female) (1) Resistance Max. 1 z
Between V23 (female) (2) and each of C02 (female)
(115), (117) and (120)
Resistance Max. 1 z
4 Defective pump controller
If no failure is found by above checks, pump controller is defective. (Since this
is an internal defect, troubleshooting cannot be performed.)
