User’s Manual
Silence Extraction Systems
(Micromotor type)
Page 24
Page 1
Body
4th Membrane filter
3rd Carbon filter
2nd ULPA filter [99.9995%]
Filter bracket
1st Medium pocket filter(450mm)
Product standard components
2
(For Brushless Motor Type, there is no 4th filter.)
※ The 1st filter replacement notification informs you when to replace by measuring the pressure
in the suction part by the pneumatic sensor.
Also, the replacement cycle of the filter may vary depending on the usage.
It is recommended to replace the 2nd, 3rd and 4th filters at least once 6~12month.
4th Filter
Membrane filter
3rd Filter
Carbon filter
2nd Filter
ULPA filter
[99.9995%]
Filter Bracket
1st Filter
1st Medium
pocket filter(450mm)
Filters of Big models1
07 Product Standard Components
