V3F25/18 drive
Installation Instruction
© 2004 KONE Corporation AM-11.65.020
All rights reserved. 40 (42) (E) 2004-01-08
0117
Shaft setup not done
Elevator does not run the
normal drive. Only RDF
(machine room inspection
drive in North America) and
inspection drives are
possible.
• Perform the shaft setup.
Other faults
0125
Torque limit exceeded
MXTORQ (6_9) parameter
shows on display -, -- or
emergency stop during
acceleration.
• Check the parameters for
MXTORQ.
• Check the motor cable
connections.
• Increase the value of
Torque
scaling (6_40)
parameter.
0126
Safety relay open
Emergency stop.
Elevator does not start.
• Check the connection of XSR1
on HCB board and control
panel.
• Check parameter
(6_38).
0127
Main contactor not
energized
Emergency stop /
Main contactor time out (2
seconds).
Check the circuits of the main
contactor (MC_SUP LED).
0128
LWD setup not done
Normal drive prevented.
Load values for Enable
LWD setup (6_74)
parameter are not set.
Perform the LWD setup.
(Minimum two values must be given)
NTS faults
0150
V1 NTS switch faulty
Elevator stops, correction
drive and returns to the
bottom floor.
Check the order and operation of
NTS switches.
0151
V1 NTS switch fault
Elevator stops, correction
drive and returns to the
bottom floor.
Check the positioning and operation
of NTS switches.
0152
V1 NTS stopping
Position lost and the
elevator stopped by the
NTS switches.
See fault 0109 “Position lost”.
Fault Symptoms of fault Action
