Kongsberg cNODE Micro Quick Reference Guide

1
2
3
4Respondertrigger+
5Respondertrigger-
6On/Off
7Externalpower(24VDC)
8Ground
Procedure
1Usethecablewithpartnumber402462fromKongsberg.
2Connectwire6and8inthepigtail(theON/OFFfunction).
When6-8arelinked,thetransponderisON.
Withnoconnectionbetween6-8,thetransponderisOFF.
3Makesurethattheexternalpowersupply24VDCisbetween20and28VDC.
4Checktherespondertriggersignal.
5SwitchONtheunitbyinsertingtheexternalpower/respondercable.
Supportinformation
ShouldyouneedtechnicalsupportforyourcNODEMiniStransponderyoumustcontactaKongsberg
Maritimeofce.Alistofallourofcesisavailableonourwebsite.Youcanalsocontactourmain
supportofceinNorway.
Manualsandtechnicalinformationcanbedownloadedfromoursupportwebsite.
CompanynameKongsbergMaritimeAS
AddressStrandpromenaden50,3183Horten,Norway
Telephone+4733034100
Telephone24hsupport+4733032407
Websitehttps://www.kongsberg.com/maritime/
SupportwebsiteProductsupportAtoZ
