Automatic Inspection Operation Manual 7-3
7.2 Setting an Inspection Area
7
Serial No. (0-9) Area
Sets an area targeted for serial No. (0-9) inspection.
This function reads and decodes the number in the target area. You can also check whether the numeric val-
ue changes sequentially. The read number must satisfy the following conditions.
- Font type: Gothic / Arial
- Font size: 8 points or more
- Background color: White
- Number of characters: 20
- There must be a margin of at least 5 mm / 0.2 inch around text.
- If [Serial No. (0-9) Area] is selected in [Select Area Type], sequential check can be set. For details, refer
to "8.4 Performing Sequential Check for the Barcode Area or Serial No. (0-9) Area" in this manual.
- If a space between numbers in the target area is narrow when a number is read in [Serial No. (0-9) Area],
a recognition error may occur.
- If [Barcode Area] or [Serial No. (0-9) Area] is selected in [Select Area Type], the decoding result is cre-
ated as a CSV file.
Specified Inspection Level Area
You can set another inspection level to the specified area. For details on how to set the automatic inspection
level, refer to "2.1.2 [Automatic Inspection Level Setting]" in this manual.
7.2 Setting an Inspection Area
Set an area that is not subject to automatic inspection, or set an area that is subject to special inspection,
such as variable printing, for example by changing part of an image intentionally.
Efficient inspection is enabled by preventing unnecessary errors and automating checks such as serial num-
ber printing.
The preview image of this function is displayed in the paper feed direction, not the crosswise direction, as
the vertical direction.
To Next Page
