14
G
ETTING UP AND RUNNING
BATTERY CONDITION INDICATOR
This camera is equipped with an automatic battery-condition indicator. When the
camera is on, the battery-condition indicator appears on the monitor. If the monitor is
blank, the batteries may be exhausted or installed incorrectly.
AUTO POWER SAVE
To conserve battery power, the camera turns off displays and unnecessary functions if
an operation is not made within a minute. To restore power, press any button or key, or
turn the exposure-mode dial to another position. The length of the auto-power-save
period can be changed in section 1 of the setup menu (p. 86).
Full-battery indicator - the battery is fully charged. This indicator is
displayed for three seconds on the monitor when the camera is turned on.
Low-battery indicator - battery power is low. The monitor will turn off
while the flash is charging to save power.
Low-battery warning - battery power is very low. The monitor indicator is
red. The battery should be replaced as soon as possible. This warning
automatically appears and remains on the monitor until the battery is
changed. The monitor will turn off while the flash is charging to save
power. If power falls below this level, the battery-exhausted message will
be displayed just before the camera shuts down. If the low-battery
warning is displayed, movie recording cannot be used.
