MOTION RECORD DURATION:
The number indicates how long motioned recording lasts after the
movements in front of the camera.
MOTION ALARM DURATION:
The number indicates how long motioned display on the screen
“MOTION”.
MOTION DETECTION SETUP:
First setup video record method by Motion Triggered. See record
schedule.
CHANNEL 1- 4 SENSITIVITY:
Press “ Select” to adjust sensitivity grade of motion detection.
High (1----------9, OFF), Low. When it’s off, the channel can not be
triggered by movement.
CHANNEL 1- 4 AREA SET:
Press “ Select” to enter area setting state, the picture of selected
channel is divided into 144 (12*12) blocks. Then press “REW” to move
left, press “FWD” to move right, press “UP” to move up, press
“DOWN” to move down, press “ Select” to set the block is active or not.
When the block is transparent, it’s active to record, when the block is
covered by shadow, it will not activate recording if motion is triggered.
