GDT-292A GDT-293A GDT-294A GDT-295A
Resistance Range Ω 200, 2k, 20k, 200k, 200, 2k, 20k, 200k 400, 4k, 40k, 326, 3.26k, 32.6k,
2M, 20M, 200M 2M, 20M, 200M 400k, 4M, 40M 326k, 3.26M, 32.6M
Base Accuracy ±0.8% ±0.8% ±0.8% ±0.8%
Capacitance Range F
– 2000p, 20n, 200n, N/A 326n, 32.6µ
2µ, 20µ
Base Accuracy – ±2.5% – ±3.0%
Frequency Range Hz
– – N/A 32.6 k, 200k
Base Accuracy – – – ±1.2% Temperature Range °F
– -122 to 1832 – –
Base Accuracy – ±0.75% – –
27
