A
Drain side
Tubing side
(Unit: mm)
680(Hook-location)
780(Hook-location)
840(Body)
840(Body)
880(Ceiling hole)
880(Ceiling hole)
950(Panel)
950(Panel)
N ece ssary room
>2500mm
outlet intlet outlet
ground
Chart 1
Chart 4
A
Note:
Nut
Bod y
Ce iling
88 0m m
Ho ok
B
Pan el
Chart 2
B ody
Chart 5
Central hole
Bolt M6X12
I nstallatio n pape r board
18000-24000Btu/h(R2 2) Series A 260m m
36000-480 00Btu/h(R 22) Series A 330mm
≥
≥
Note:
18000-2400 0Btu/h(R22 ) Series B=240mm
36000-4800 0Btu/h(R22) Series B=310mm
12 Four-way Ceiling Cassette Type
