5. Capacity Tables
6.1 Cooling Capacity
KV24CM-ARF21
Cooling Outdoor conditions (DB)
Indoor Conditions (kW) 21ºC 28ºC 35ºC 43ºC
21/15ºC DB/WB
TC 7.52 7.15 6.79 6.50
SC 5.56 5.51 5.43 5.46
Input 2.10 2.28 2.38 2.46
24/17ºC DB/WB
TC 7.74 7.37 7.01 6.57
SC 5.80 5.75 5.68 5.52
Input 2.23 2.38 2.49 2.61
27/19ºC DB/WB
TC 7.88 7.52 7.30 6.79
SC 5.83 5.79 5.69 5.57
Input 2.28 2.41 2.54 2.66
32/23ºC DB/WB
TC 8.03 7.74 7.59 7.01
SC 6.83 6.73 6.68 6.52
Input 2.38 2.49 2.66 2.76
KV36CM-ARF21
High speed Indoor conditions (DB) at 0Pa
Indoor Conditions (kW) 21ºC 28ºC 35ºC 43ºC
21/15ºC DB/WB
TC 10.82 10.29 9.77 9.35
SC 8.00 7.92 7.81 7.85
Input 3.44 3.73 3.89 4.02
24/17ºC DB/WB
TC 11.13 10.61 10.08 9.45
SC 8.35 8.27 8.16 7.94
Input 3.64 3.89 4.06 4.26
27/19ºC DB/WB
TC 11.34 10.82 10.50 9.77
SC 8.39 8.33 8.19 8.01
Input 3.73 3.93 4.14 4.35
32/23ºC DB/WB
TC 11.55 11.13 10.92 10.08
SC 9.82 9.68 9.61 9.37
Input 3.89 4.06 4.35 4.51
KV48CM-ARF21
Cooling Outdoor conditions (DB)
Indoor Conditions (kW) 21ºC 28ºC 35ºC 43ºC
21/15ºC DB/WB
TC 14.42 13.72 13.02 12.46
SC 10.67 10.56 10.42 10.47
Input 3.89 4.22 4.41 4.55
24/17ºC DB/WB
TC 14.84 14.14 13.44 12.60
SC 11.13 11.03 10.89 10.58
Input 4.13 4.41 4.60 4.83
27/19ºC DB/WB
TC 15.12 14.42 14.00 13.02
SC 11.19 11.10 10.92 10.68
Input 4.22 4.45 4.69 4.92
32/23ºC DB/WB
TC 15.40 14.84 14.56 13.44
SC 13.09 12.91 12.81 12.50
Input 4.41 4.60 4.92 5.11
Notes:
TC : Total capacity ; kW
SC: Sensible heat capacity ; kW
Input: Input power; kW
