F4: AUTO WAH
This models an auto wah unit that automatically applies a wah effect according to your picking dynamics (i.e.,
the strength with which you pick the strings). As with the VOX WAH, you can select either V847 or V848 as the
wah type.
Main SENS/POL Adjusts the sensitivity of the wah to the volume of your guitar.
P1 ATTACK Adjusts the response speed.
P2 ORDER Selects the connection order.
PRE/POST connects the wah before/after the Drive/Amp Model.
P3 TYPE Selects either 47 (V847) or 48 (V848) as the wah type.
F5: VIB/PH (U-VIBE/PHASE)
This lets you select one of three models; a famous phase/vibrato effect with a pedal, a wide-range four-stage
phaser that was made in Denmark and packaged in a black box, and a popular four-stage phaser that came in a
banana-colored box. Use the TYPE to select the model.
Main SPEED Adjusts the vibrato/modulation speed.
P1 DEPTH Adjusts the vibrato/modulation depth.
P2 ORDER Selects the connection order. PRE/POST connects the effect before/after the Amp
Model.
P3 TYPE Selects the type.
U1: U-VIBE set to Vibrato mode.
U2: U-VIBE set to Chorus mode.
or: Models the popular four-stage phaser.
bL: Models the Danish phaser.
P4 MANUAL Adjusts the center frequency of the sweep. MANUAL has no effect if DEPTH is set to
10.
F6: CH/FLN (CHORUS/FLANGER)
This is a chorus/flanger unit with a standard circuit structure.
Main SPEED Adjusts the modulation speed.
P1 DEPTH Adjusts the modulation depth.
P2 RESO Adjusts the amount of resonance.
P3 MANUAL Adjusts the center frequency of the sweep. MANUAL has no effect if DEPTH is set to
10.
F7: OCTAVE
This models a pedal that generates a pitch one octave below the original input, mixing it with the original sound
to add thickness.
This type of effect only works with single notes; chords will confuse it.
Main EFFECT Adjusts the mix level of the note one octave below.
P1 DIRECT Adjusts the mix level of the original sound.
F8: RING MOD (RING MODULATOR)
This is a ring modulator; an effect that uses an oscillator to generate a sine wave which is then multiplied with the
signal from your guitar to produce new harmonics.
Main OSCFREQ Adjusts the oscillator frequency.
P1 EFFECT Adjusts the mix level of the effect sound.
P2 DIRECT Adjusts the mix level of the original sound.
P3 FILTER Adjusts the filter cutoff frequency.
