49
Appendices
Block diagramIndex TroubleshootingVarious messages
Specifications
Song file detailsFunction Lists
Specifications
■ Main sections
<Recorder section>
<MIDI Functionality>
<Mixer section>
<Effect section>
<General>
■ Principal specifications
■ Analog/digital input and output spec-
ifications
Indications in square brackets [ ] are when output assign
is INDIVIDUAL
<INPUT 1–8>
<MONITOR OUTPUT L/R> [CH 1, 2]
<MASTER OUTPUT L/R> [CH 3, 4]
<CH 5–8> [CH 5–8]
<PHONES>
<S/P DIF OUTPUT>
<USB>
<MIDI IN/OUT>
<FOOT SW>
■ Included items
■ Options (sold separately)
* Appearance and specifications of this product are
subject to change without notice. (02, 2006)
Operating temperature:
+5 – +35 °C (do not allow condensation)
Number of tracks: 64 + master tracks*
(including virtual tracks)*
Simultaneous playback 8 tracks,
simultaneous recording 8 tracks
* For stereo WAV files; number of tracks
will depend on the free capacity of the
hard drive
Recording format: 44.1 kHz/16-bit uncompressed
Recording time: Maximum 124 hours*
* when using a 40 GB hard drive
Maximum six hours continuous
Number of songs: Maximum 100 songs
Mark points: 100 points per song (no mark names)
USB functions: Connects to a computer via USB 2.0, and
functions as a FAT 32 USB external drive
Track editing: Copy (overwrite), erase, swap, assign WAV
files to tracks
Song editing: Copy, delete, rename, protect, save now
Metronome =40–250, Time signature=0, 2, 3, 4, 6, 8
MTC transmission: frame rate 30 fps, format 30 NDF
Structure: 8-channel input (8 bus), monitor x 1,
master x 1, internal effect send x 1
Signal processing 40 bit, 44.1 kHz
Equalizer: HIGH (Fc: 10 kHz, G: ±15 dB)
MID (Fc: 2.5 kHz, G: ±15 dB)
LOW (Fc: 100 Hz, G: ±15 dB)
Structure: Master × 1
Signal processing 40 bit, 44.1 kHz
Programs: 11
Display: 160 × 104 pixel, movable LCD with backlight
Power supply: AC Local Voltage
Power consumption:
32 W
Dimensions: 375 mm (W) × 331 mm (D) × 110 mm (H)
15.3" (W) × 13" (D) × 4.3" (H)
Weight: 4.4 kg/9.7 lbs
Frequency response:
10 Hz – 20 kHz +1 dB/–2 dB
S/N: 96 dB (typical) @IHF-A
THD+N: 0.03% (typical) 20 Hz–20 kHz
A/D conversion: 24-bit 64 times oversampling
D/A conversion: 24-bit 128 times oversampling
Sampling frequency: 44.1 kHz
Record/Playback bit: 16-bit
Connectors: XLR-3-31 type (+48 V phantom power,
switchable), 1/4" TRS phone jack (balanced)
Input impedance: 4 kΩ (XLR-3-31), 10 kΩ (TRS phone jacks)
Nominal level: –60 dBu to +4 dBu @ TRIM=max. – min.
Maximum level: –48 dBu to +16 dBu @ TRIM=max. – min.
Source impedance: 600 Ω
Connectors: 1/4" phone jack (unbalanced)
Output impedance: 500 Ω
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 kΩ or higher
Connectors: 1/4" phone jack (unbalanced)
Output impedance: 500 Ω
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 kΩ or higher
Connectors: 1/4" phone jack (unbalanced)
Output impedance: 500 Ω
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 kΩ or higher
Connector: 1/4" stereo phone jack × 2
Output impedance: 100 Ω
Maximum level: 50 mW+50 mW @ 32 Ω
Connector: optical
Format: 24-bit S/P DIF (IEC60958)
Connector: Type B
Format: USB2.0 High-Speed device
USB Mass Storage Class
Supported OS: Window Me, Windows 2000 or later
Mac OS 9.0.4 or later
* If using the D888 with Windows 98, please
refer to the Korg website or contact your
Korg distributor.
Connectors: DIN 5-pin
Connector: 1/4" phone jack (use separately sold PS-1)
AC cable
Owner’s manual
PS-1 pedal switch
SpecificationsBlock diagram
