As shown in the table below to set up a mult i-met er.
FUN CTI ON Rat e
The deci mal point
DCV SL OW
Triple digi t s
Please connect t he cable for t esting CV./Gat e t o the mut imat or.
(Please see page ? of No3 cir cuit diagr am of thi s cable.)
Connect to the CV ter minal of the mult i met er to V of this cable.
And connect t o the GND ter minal of the mul timater to GND of t his cable.
Please set up a mir r or so you can see the L ED of t he hole in the "R" print ed char act er s
"KORG" of the rear.
1. Star t TEST M ODE
Pr ess the power swit ch for mor e than 1 second while holding down the 3 swi tches
[FAVORI TES], [PAGE -], and [STRI NGS]
2. Checking t he syst em ver sion
Ver sion of the main system i s displayed on the main display. (Left photo bel ow)
Ver sion of the panel system i s di splayed on t he sub-displ ay to the right . (Upper r ight photo)
Aft er check ing the ver sion, and pr ess the [VAL U E dial], (int er nal inspection) is star t ed the
next inspecti on.
3-1. I nter nal Test
The test will st ar t aut omatically.(I nspection wil l st ar t automatically when you pr ess t he
[VAL UE dial] in the pr evious st ep.)
The foll owing checks will be executed.
I tem cont ent s
WORK RAM Check execute on RAM pr og.
Flash ROM Check sum
DSP SDRAM Check bus
PAN EL Check sum
USB Check a command response.
M I DI LOOP I N/OU T self check
CV DAC cont r ol line check
