2. RECOGNIZED RECEIVE DATA
2-1 CHANNEL MESSAGES [H] :Hex, [D] :Decimal
+------+---------+--------------------+---------------------------------------------------------------------+----+
|Status| Second | Third | Description ( Use ..... ) |ENA |
|[Hex] |[H] [D] | [H] [D] | | |
+------+---------+--------------------+---------------------------------------------------------------------+----+
| 8n | kk (kk) | xx (xx) | Note Off | A |
| 9n | kk (kk) | 00 (00) | Note Off | A |
| 9n | kk (kk) | vv (vv) | Note On (vv) = 1-127 | A |
| An | kk (kk) | vv (vv) | Poly Key Pressure ( as AMS ) | T,Q|
| Bn | 00 (00) | mm (mm) | Bank Select(MSB) ( for Prog/Combi change ) *1| P |
| Bn | 01 (01) | vv (vv) | Modulation1 ( as Joy Stick +Y ) | C |
| Bn | 02 (02) | vv (vv) | Modulation2 ( as Joy Stick -Y ) | C |
| Bn | 04 (04) | vv (vv) | Foot Pedal ( as AMS & FX Dmod Src = Foot Pedal ) | C |
| Bn | 05 (05) | vv (vv) | Portamento Time | C |
| Bn | 06 (06) | vv (vv) | Data Entry (MSB) ( for RPC edit ) | C |
| Bn | 07 (07) | vv (vv) | Volume | C |
| Bn | 08 (08) | vv (vv) | Balance Control ( for Post IFX Panpot control ) *2| C |
| Bn | 0A (10) | vv (vv) | Panpot | C |
| Bn | 0B (11) | vv (vv) | Expression | C |
| Bn | 0C (12) | vv (vv) | Effect Control 1 ( as FX Dmod Src = Fx Control1 ) | C |
| Bn | 0D (13) | vv (vv) | Effect Control 2 ( as FX Dmod Src = Fx Control2 ) | C |
| Bn | 0E (14) | vv (vv) | ( as ARP ON/OFF ) *4| C |
| Bn | 10 (16) | vv (vv) | Multi Purpose Ctrl1 ( as AMS & FX Dmod Src = Ribbon CC#16 ) | C |
| Bn | 11 (17) | vv (vv) | Multi Purpose Ctrl2 ( as AMS & FX Dmod Src = Knob Mod1 ) | C |
| Bn | 12 (18) | vv (vv) | Multi Purpose Ctrl3 ( as AMS & FX Dmod Src = Value Slider CC#18 ) | C |
| Bn | 13 (19) | vv (vv) | Multi Purpose Ctrl4 ( as AMS & FX Dmod Src = Knob Mod2 ) | C |
| Bn | 14 (20) | vv (vv) | ( as AMS & FX Dmod Src = Knob Mod3 ) | C |
| Bn | 15 (21) | vv (vv) | ( as AMS & FX Dmod Src = Knob Mod4 ) | C |
| Bn | 16 (22) | vv (vv) | ( as ARP Knob1 GATE ) *4| C |
| Bn | 17 (23) | vv (vv) | ( as ARP Knob2 VELOCITY ) *4| C |
| Bn | 18 (24) | vv (vv) | ( as ARP Knob3 SWING ) *4| C |
| Bn | 19 (25) | vv (vv) | ( as ARP Knob4 STEP ) *4| C |
| Bn | 20 (32) | bb (bb) | Bank Select(LSB) ( for Prog / Combi change ) *1| P |
| Bn | 26 (38) | vv (vv) | Data Entry (LSB) ( for RPC edit ) | C |
| Bn | 40 (64) | vv (vv) | Hold1 ( as Damper) | C |
| Bn | 41 (65) |<=3F/>=40(<=63/>=64)| Portamento Off/On | C |
| Bn | 42 (66) |<=3F/>=40(<=63/>=64)| Sostenuto Off/On | C |
| Bn | 43 (67) | vv (vv) | Soft Pedal | C |
| Bn | 46 (70) | vv (vv) | Sound Controller 1 ( for Sustain Level control ) | C |
| Bn | 47 (71) | vv (vv) | Sound Controller 2 ( for Resonance control ) | C |
| Bn | 48 (72) | vv (vv) | Sound Controller 3 ( for Release Time control ) | C |
| Bn | 49 (73) | vv (vv) | Sound Controller 4 ( for Attack Time control ) | C |
| Bn | 4A (74) | vv (vv) | Sound Controller 5 ( for Filter Cutoff control ) | C |
| Bn | 4B (75) | vv (vv) | Sound Controller 6 ( for Decay Time control ) | C |
| Bn | 4C (76) | vv (vv) | Sound Controller 7 ( for LFO1 Speed control ) | C |
| Bn | 4D (77) | vv (vv) | Sound Controller 8 ( for LFO1 Pitch Depth control ) | C |
| Bn | 4E (78) | vv (vv) | Sound Controller 9 ( for LFO1 Delay control ) | C |
| Bn | 4F (79) | vv (vv) | Sound Controller 10 ( for Filter EG Intensity control ) | C |
| Bn | 50 (80) | vv (vv) | Multi Purpose Ctrl5 ( as AMS & FX Dmod Src = SW 1 ) | C |
| Bn | 51 (81) | vv (vv) | Multi Purpose Ctrl6 ( as AMS & FX Dmod Src = SW 2 ) | C |
| Bn | 52 (82) | vv (vv) | Multi Purpose Ctrl7 ( as AMS & FX Dmod Src = Foot Switch ) | C |
| Bn | 53 (83) | vv (vv) | Multi Purpose Ctrl8 ( as AMS & FX Dmod Src = CC#83 ) | C |
| Bn | 55 (85) | vv (vv) | ( as AMS & FX Dmod Src = CC#85 ) | C |
| Bn | 56 (86) | vv (vv) | ( as AMS & FX Dmod Src = CC#86 ) | C |
| Bn | 57 (87) | vv (vv) | ( as AMS & FX Dmod Src = CC#87 ) | C |
| Bn | 58 (88) | vv (vv) | ( as AMS & FX Dmod Src = CC#88 ) | C |
| Bn | 5B (91) | vv (vv) | Effect 1 Depth ( for Send 2 Level control ) | C |
| Bg | 5C (92) |00/!=00 (00/!=000)| Effect 2 Depth ( for All Insert FX Off/On ) | C |
| Bn | 5D (93) | vv (vv) | Effect 3 Depth ( for Send 1 Level control ) | C |
| Bg | 5E (94) |00/!=00 (00/!=000)| Effect 4 Depth ( for Master FX1,2 Off/On ) | C |
| Bg | 5F (95) |00/!=00 (00/!=000)| Effect 5 Depth ( for Total FX Off/On ) | C |
| Bn | 60 (96) | 00 (00) | Data Increment ( for RPC edit ) | C |
| Bn | 61 (97) | 00 (00) | Data Decrement ( for RPC edit ) | C |
| Bn | 64 (100)| 0r (0r) | RPN Param No. (LSB) ( for RPN select ) *3| C |
| Bn | 65 (101)| 00 (00) | RPN Param No. (MSB) ( for RPN select ) *3| C |
| Bn | cc (cc) | vv (vv) | Control data ( for Seq. recording (cc) = 0-119 ) | C,Q|
| Bn | 78 (120)| 00 (00) | All Sound Off | C |
| Bn | 79 (121)| 00 (00) | Reset All Controllers | C |
| Bn | 7A (122)| 00/7F (00/127) | Local Control Off/On | A |
| Bn | 7B (123)| 00 (00) | All Notes Off | A |
| Bn | 7C (124)| 00 (00) | Omni Mode Off ( as All Notes Off ) | A |
| Bn | 7D (125)| 00 (00) | Omni Mode On ( as All Notes Off ) | A |
| Bn | 7E (126)| <=10 (<=16) | Mono Mode On ( as All Notes Off ) | A |
| Bn | 7F (127)| 00 (00) | Poly mode On ( as All Notes Off ) | A |
| Cn | pp (pp) | -- -- | Program Change ( for Prog/Combi change ) *1| P |
| Dn | vv (vv) | -- -- | Channel Pressure ( as After Touch ) | T |
| En | bb (bb) | bb (bb) | Bender Change | C |
+------+---------+--------------------+---------------------------------------------------------------------+----+
1-3 SYSTEM REALTIME MESSAGES
+------------+------------------------------------------------------------+
|Status[Hex] | Description ( Transmitted when ... ) |
+------------+------------------------------------------------------------+
| F8 | Timing Clock ( Always in Prog/Combi/Seq/Global mode ) *5|
| FA | Start ( START in Seq mode ) *5|
| FB | Continue ( Continue START in Seq mode ) *5|
| FC | Stop ( STOP in Seq mode ) *5|
| FE | Active Sensing ( Always ) *6|
+------------+------------------------------------------------------------+
*5 Transmits these messages when MIDI Clock in Global mode is Internal.
*6 Transmits this message when MIDI Clock in Global mode is External.
1-4 SYSTEM EXCLUSIVE
1-4-1 UNIVERSAL SYSTEM EXCLUSIVE MESSAGE ( NON REALTIME )
DEVICE INQUlRY REPLY ( Transmits when received a INQUIRY MESSAGE REQUEST )
[ F0,7E,0g,06,02,42,52,01,mm,00,vv,ww,xx,00,F7 ] 3rd byte g : Global Channel
6th byte 42 : KORG ID
7th byte 52 : KROME EX series ID LSB
8th byte 01 : KROME EX series ID MSB
9th byte mm : KROME EX 61Keys member code mm = 05
KROME EX 73Keys member code mm = 0E
KROME EX 88Keys member code mm = 17
11th byte vv : System Version 1st ( 1 - )
12th byte ww : System Version 2nd ( 0 - )
13th byte xx : System Version 3rd ( 0 - )
(i.e. Version 1.0.2: vv=01, ww=00, xx=02 )
1-4-2 UNIVERSAL SYSTEM EXCLUSIVE MESSAGES ( REALTIME )
Master Volume
[ F0,7F,0g,04,01,vv,mm,F7 ] 3rd byte g : Global Channel
6th byte vv : Value(LSB)
7th byte mm : Value(MSB)
mm,vv = 00,00 - 7F,7F : Min - Max
