Selecting Programs, Combinations and Other Sounds
En-3
Selecting Programs,
Combinations and Other Sounds
Here’s how to select the new sounds added to the
KROME EX.
These instructions show how to select the banks that
have been added for programs and combinations.
Banks have not been added for all other sounds (data
has been added within the banks), so the method of
selecting banks is basically the same as for the
KROME. The relevant pages for selecting those sounds
will be listed.
Selecting banks for programs and
combinations
Select the program bank using the BANK A–F
buttons
1. Select “Program Select” in Program, Combination,
or Sequencer mode.
2. Press the BANK A–F buttons to switch the bank.
Press the lit button to select the U banks (U-A–U-F).
The corresponding button will blink.
Press a blinking or dark (unlit) button to select
banks A–F. The corresponding button will light.
Select the combination bank using the BANK
A–F buttons
1. Select “Combination Select” in Combination
mode.
2. Press the BANK A–F buttons to switch the bank.
The corresponding button will light.
Selecting banks for programs and
combinations on the display
• Press the pop-up button ( ) to the left side of
“Program Select” in Program, Combination or
Sequencer mode to display the Bank/Program
Select menu.
Use the tabs to the left and right of the display to
select banks.
• Press the pop-up button to the left side of
“Combination Select” in Combination mode. The
Bank/Combination Select menu appears.
Use the tabs to the left side of the display to select
banks.
Program mode
“Program Select”
Combination mode
“Program Select”
Sequencer mode
“Program Select”
BANK A–F buttons
Number of programs: BANK A–F (stays lit), BANK U–A to U–F (blinks)
Combination: BANK A–F (stays lit)
Combination mode “Combination Select”

Korg Krome EX Specifications

General

Sound Engine	EDS-X (Enhanced Definition Synthesis-eXpanded)
Resolution	1/480
MIDI	In, Out
Polyphony	120 voices
Combinations	512 user combinations
Drum Kits	48 user drum kits
Effects	5 Insert Effects, 2 Master Effects, 1 Total Effect
Display	7-inch color TFT touchscreen
Sequencer	16 tracks
Arpeggiator	Yes
PCM Memory	4 GB
Number of Songs	Max. 128 Songs
Tempo	40.00 – 300.00 BPM
Number of Set List	128 set lists
Audio Outputs	L/MONO, R, Headphones
Audio Inputs	L/MONO, R (1/4" jacks)
USB	USB (TYPE B) x 1 (MIDI Interface), USB (TYPE A) x 1 (data storage)
SD Card Slot	Yes (SDHC compatible)
Power Supply	AC adapter (DC12V)
Dimensions (88-key)	1, 448 mm x 383 mm x 131 mm
Weight (61-key)	7.2 kg
Weight (73-key)	8.2 kg
Keyboard	61-key: Natural Touch Semi Weighted keyboard 73-key: Natural Touch Semi Weighted keyboard 88-key: Natural Weighted Hammer Action keyboard
