The BANK SIDE key blinks in orange and all PRO-
GRAM NUMBER keys light up.
2.
Press a PROGRAM NUMBER key to select the favor-
ite program assigned to it.
3.
To exit Favorites mode, press the BANK SIDE key .
Note:
The Favorites mode can also be exited by turning the
BANK SELECT dial
.
Listening to the demo songs
The microKORG S contains several demo songs.
1.
Hold down the SHIFT key and press the ARPEG-
GIATOR ON/OFF key
.
2.
To switch the demo song during playback, press the OC-
TAVE SHIFT UP or DOWN key
.
You can also use the PROGRAM NUMBER 1 – 8 keys
to
select a demo song.
3.
When you press the SHIFT key , demo playback will
stop.
Turning the microKORG S o
1.
Turn the VOLUME knob to lower the volume.
2.
Hold down the power switch until the display goes
o ff .
Since all program data that has not been saved will be
lost when the microKORG S is turned off , be sure to fi rst
save your edits. Favorites, some GLOBAL parameters,
MIDI parameters and SHIFT functions (“MIDI FILTER”,
“CONTROL CHANGE” and “WRITE PROTECT”) will
automatically be saved.
Do not turn off the microKORG S while a process such as
saving is being performed. Otherwise, data in the memo-
ry of the microKORG S may be corrupted.
The Auto Power-Off Function
The auto power-off function automatically turns off the mi-
croKORG S if it is not played or operated* for a set period of
time. The factory default se ing is 4 hours.
* Turning the VOLUME knob is not considered an op-
eration.
Setting the Auto Power-Off function
1.
While holding down the ARPEGGIATOR ON/OFF key
, press the power switch .
The display will indicate the current setting of the auto
power-off function (“
”/“ ”), and the PROGRAM
NUMBER 1 key
will blink.
2.
Press the PROGRAM NUMBER 1 key .
The se ing will alternately be enabled or disabled each time
you press the key.
Enable (
): The power will automatically turn off when
four hours have elapsed since the keyboard or switches were
used. (Auto power-off is enabled.)
Disable (
): The power will not turn off automatically.
(Auto power-off is disabled.)
When you change the se ing, the WRITE key
will blink.
3.
To save the se ing, press the WRITE key .
The display will indicate “
” and the setting will be
saved. Then the microKORG S will restart automatically.
If you don’t want to save the setting or if you’ve changed
your mind, turn off the power by holding down the power
switch
until the display goes blank.
Inserting/exchanging batteries
The microKORG S can also be operated on ba eries.
Batteries are not included. You will need to purchase
them separately.
1.
Make sure that the power switch on
the microKORG S is turned off . Then
open the ba ery cover located on the
bo om of the case.
2.
Insert six AA alkaline ba eries.
Be careful to observe the correct po-
larity of the ba eries.
3.
Close the ba ery cover.
When the battery charge is low,
“ ” appears in the display and you will not be able
to save your data. In this case, connect the AC adapter
or replace the ba eries; then adjust the se ing again and
save it.
Speci cations (abbreviated)
Tone generator System:
Analog modeling systhesis system
•
Synth programs:
Number of timbres : maximum 2 (when using
Layer), Maximum polyphony : 4 voices
•
Vocoder programs:
Maximum polyphony : 4 voices
Keyboard:
37 notes (mini keyboard, velocity sensitive, no
aftertouch)
E ects:
Modulation eff ect, Delay, Equalizer
Arpeggiator:
UP, DOWN, ALT1/2, Random, Trigger (6 types),
Step Arpeggiator function
Programs:
total 256 programs (A/B/C/D side x 8 banks x 8
programs)
INPUTS:
•
Audio IN 1 Condenser jack:
with MIC/LINE switch, Connector +5V
mini-phone jack
•
Audio IN 1 DYNAMIC jack:
with MIC/LINE switch, Connector 1/4”
phone jack (unbalanced),
•
Audio IN 2 LINE jack:
Connector 1/4” phone jack (unbalanced)
Outputs:
L/MONO, R jacks, HEADPHONES jack
MIDI:
IN, OUT, THRU connectors
Amp output/speaker:
3W/4cm x 1, 0.5W/3.5cm x 2
Display:
3-digit x 1 line eight-segment LED
Power supply:
Included DC 9V AC adapter, six AA ba eries
Battery life:
approximately 4 hours or more (when using
alkaline ba eries)
Dimensions:
524 x 232 x 70 mm / Inches: 20.63” x 9.13” x 2.76”
(W x D x H)
Weight:
2.5 kg / 5.51 lbs. (without ba eries and included
microphone)
Included items:
condenser microphone, AC adapter (DC 9V
), Quick Start Guide
* Appearance and specifications of this product are subject to
change without notice.
