microKORG XL+
90
4. Front panel knob/button control
change assignments
Control changes can be assigned to each front panel knob/button of the
microKORG XL+ so that the changes in sound as controlled by knob/but-
ton operations can be transmitted as performance data.
NOTE For details on assigning control changes to the microKORG XL+ ’s
knobs and buttons, refer to page 61 “CC MAP (MIDI Control Change No.
Map)”.
NOTE Different parameters are assigned to synth parameters and vocoder pa-
rameters.
If you are using two microKORG XL+ units to transmit and receive
these parameters, you must set the transmitting and receiving pro-
grams to the same settings.
Page Parameter Initial Value (transmitted) Value (received)
UNISON
MODE CC#03 0...31: OFF, 32...63: 2VOICE, 64...95: 3VOICE, 96...127: 4VOICE 0...31: OFF, 32...63: 2VOICE, 64...95: 3VOICE, 96...127: 4VOICE
PITCH PORTMNTO CC#05 0...127 0...127
OSC1
WAVE CC#08
0...15: SAW, 16...31: PULSE, 32...47: TRIANGLE, 48...63: SINE,
64...79: FORMANT, 80...95: NOISE, 96...111: PCM/DWGS,
112...127: AUDIO IN
0...15: SAW, 16...31: PULSE, 32...47: TRIANGLE, 48...63: SINE,
64...79: FORMANT, 80...95: NOISE, 96...111: PCM/DWGS,
112...127: AUDIO IN
OSC MOD CC#09
0...31: WAVEFORM, 32...63: CROSS, 64...95: UNISON, 96...127:
VPM
0...31: WAVEFORM, 32...63: CROSS, 64...95: UNISON, 96...127:
VPM
OSC1.C1 CC#15 0...127 0...127
OSC1.C2 CC#17 0...127 0...127 (OSC MOD=VPM: 1...32:0...127)
OSC2
WAVE CC#18 0...31: SAW, 32...63: PULSE, 64...95: TRIANGLE, 96...127: SINE 0...31: SAW, 32...63: PULSE, 64...95: TRIANGLE, 96...127: SINE
OSC MOD CC#19 0...31: OFF, 32...63: RING, 64...95: SYNC, 96...127: RING.SYNC 0...31: OFF, 32...63: RING, 64...95: SYNC, 96...127: RING.SYNC
SEMITONE CC#20  p. 41 “SEMITONE (Oscillator 2 Semitone)”  p. 41 “SEMITONE (Oscillator 2 Semitone)”
TUNE CC#21 0...127 0...127
MIXER
OSC1 LVL CC#23 0...127 0...127
OSC2 LVL CC#24 0...127 0...127
NOISE.LVL CC#25 0...127 0...127
FILTER1
CUTOFF CC#74 0...127 0...127
RESO CC#71 0...127 0...127
TYPE BAL CC#27  p. 92 ““TYPE BAL” values”  p. 92 ““TYPE BAL” values”
ROUTING1 CC#26
0...31: SINGLE, 32...63: SERIAL, 64...95: PARALLEL, 96...127:
INDIV
0...31: SINGLE, 32...63: SERIAL, 64...95: PARALLEL, 96...127:
INDIV
EG1 INT CC#79 0/1: –63, 2: –62...63: –1, 64: 0, 65: +1...127: +63 0/1: –63, 2: –62...63: –1, 64: 0, 65: +1...127: +63
KEY TRK CC#28 0/1: –2... 64: 0...127: +2 0/1: –2... 64: 0...127: +2
